ISO 2867 pdf download Earth-moving machinery — Access systems
1 Scope
This International Standard specifies criteria for systems that provide access to the operator station and to routine maintenance points on earth-moving machinery as defined in ISO 6165. It is applicable to the access systems (e.g. enclosure openings, platforms, guardrails, handrails and handholds, stairways and steps, ladders) on such machines parked in accordance with the manufacturer’s instructions. Its criteria are based on the 5th to 95th percentile operator dimensions as defined in ISO 3411. It deals with the following significant hazards, hazardous situations and events: slip, trip and fall of persons, unhealthy postures and excessive effort.
The general principles set out in this International Standard can be used for the selection of fixed and/or portable access systems for repairs, assembly, disassembly and longer interval maintenance.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 3411, Earth-moving machinery — Physical dimensions of operators and minimum operator space envelope
ISO 6165, Earth-moving machinery — Basic types — Identification and terms and definitions
ISO 12508, Earth-moving machinery — Operator station and maintenance areas — Bluntness of edges
ISO 14122-1:2001, Safety of machinery — Permanent means of access to machinery — Part 1: Choice of fixed means of access between two levels
ISO 14122-4, Safety of machinery — Permanent means of access to machinery — Part 4: Fixed ladders
ISO 14567, Personal protective equipment for protection against falls from a height — Single-point anchor devices
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1 General terms and definitions
3.1.1
target dimension
dimensional value that takes into account ergonomics criteria based on comfort
NOTE Acceptable values are within the specified range (from minimum to maximum).
3.1.2
machine repairs
work on a machine that is done as a result of a machine failure
3.1.3
routine maintenance points
locations on a machine that are specified in the periodic maintenance schedule of the operator’s manual for performing scheduled daily/weekly/monthly maintenance on the machine
3.1.4
two-point support
feature of an access system that enables a person to use, simultaneously, both feet, or one hand and one foot,while ascending, descending or moving about on the machine
3.1.5
three-point support
feature of an access system that enables a person to use, simultaneously, both hands and one foot, or both feet and one hand, while ascending, descending or moving about on the machine
3.1.6
operator station
area from which an operator controls the travel and work functions of the machine
3.1.7
ground
surface on which a machine is positioned, taking into account full penetration of pad feet or track grousers
See Figure 1.
