IEC 61204 pdf download Low-voltage power supply devices, d.c. output – Performance characteristics
1General
1.1Scope and object
This international Standard describes a method for specifying requirements for low-voltagepower supply devices (including switching types) providing d.c.output(s) up to 200 v d.c. at apower level of up to 30 kW, operating from a.c. or d.c. source voltages of up to 60o v.
The devices are for use within class l equipment or for free-standing operation when usedwith adequate electrical and mechanical protection.
This standard is intended to be used for all types of a.c. or d.c. driver power supplies with anynumber of outputs, specially produced for an unknown final application.
ln the case where power supplies are developed as a component of equipment covered byspecific product standards, these standards apply; the additional application of lEC 61204may be useful as an option, especially if the performance characteristics are not sufficientlycovered by the product standard.
lt permits to specify a power unit to meet a particular application by the specification of parameters at required performance levels, to establish the essential definitions related to thistype of equipment,and to establish a selection of levels of performance.These levels arecarefully graded to enable manufacturers and users to select and specify a range of powersupply devices suitable for their application.
1.2 Normative references
The following normative documents contain provisions which, through reference in this text,constitute provisions of this International Standard.At the time of publication, the editionsindicated were valid.All normative documents are subject to revision, and parties to agreements based on this International Standard are encouraged to investigate the possibilityof applying the most recent editions of the normative documents indicated below. Members oflEC and lSo maintain registers of currently International Standards.
IEC 60038:1983,IEC standard voltages
IEC 60068: Environmental testing
IEC 60068-2-1:1990,Environmental testing – Part 2: Tests- Tests A: ColdIEC 60068-2-2:1974，Environmental testing -Part 2: Tests – Tests B: Dry heat
IEC 60068-2-3:1969, Environmental testing – Part 2:Tests-Test Ca: Damp heat, steadystate
IEC 60068-2-6:1982,Environmental testing – Part 2: Tests-Test Fc and guidance:Vibration (sinusoidal)
IEC 60068-2-27:1 987, Environmental testing – Part 2: Tests – Test Ea and Guidance: Shock
IEC 60068-2-29:1 987, Environmental testing – Part 2: Tests – Test Eb and Guidance: Bump
IEC 60478: Stabilized power supplies, d.c. output
IEC 60478-1 :1 974, Stabilized power supplies, d.c. output – Part 1: Terms and definitions
IEC 60478-2:1 986, Stabilized power supplies, d.c. output – Part 2: Rating and performance
IEC 60478-3:1 989, Stabilized power supplies, d.c. output – Part 3: Reference levels and measurement of conducted electromagnetic interference (EMI)
IEC 60478-4:1 976, Stabilized power supplies, d.c. output – Part 4: Tests other than radiofrequency interference
IEC 60478-5:1 993, Stabilized power supplies, d.c. output – Part 5: Measurement of the magnetic component of the reactive near field
IEC 60651 :1 979, Sound level meters
