1Scope
This International Standard specifies the requirements of bunched solderable polyurethaneenamelled round copper winding wires, class 130, with silk covering.
This covering consists of one or two layers of silk.
The single wire is a solderable polyurethane enamelled round copper winding wire, class 130(IEC 60317-4).
When reference is made to a winding wire according to the present standard, the followinginformation is given in the description:
– reference to lEC specification;
– number of wires and the nominal diameter of one wire in millimetres.
EXAMPLE: IEC60317-11 -25·0,071
2Normative references
The following referenced documents are indispensable for the application of this document.For dated references, only the edition cited applies.For undated references, the latest editionof the referenced document (including any amendments) applies.
IEC 60317-O-1,Specifications for particular types of winding wires – Part 0-1 : Generalrequirements – Enamelled round copper wire
IEC 60317-4,Specifications for particular types of winding wires – Part 4: Solderablepolyurethane enamelled round copper wire, class 130
IEC 60851(all parts), Winding wires – Test methods
3 3.1
Definitions and general notes on methods of test Definitions
3.1.1
bunched wire
a wire consisting of a number of small diameter insulated wires laid-up together without predetermined geometrical position and with or without additional covering
3.1.2
class
the thermal performance of a wire expressed by the temperature index and the heat shock temperature
3.1.3
coating
a material which is deposited on a conductor or wire by a suitable means and then dried and/or cured
3.1.4
conductor
the bare metal after removal of the insulation
3.1.5
covering
a material which is wound, wrapped or braided around a bare or insulated conductor
3.1.6
enamelled wire
a wire coated with an insulation of cured resin
3.1.7
grade
the range of thickness of the insulation of a wire
3.1.8
insulation
a coating or covering on the conductor with the specific function of withstanding voltage
3.1.9
nominal conductor dimension
the designation of the conductor size in accordance with IEC 60317
3.1.10
winding wire
a wire used for winding a coil to provide a magnetic field
3.1.11
wire
a conductor coated or covered with an insulation
3.2 General notes on methods of test
All methods of test to be used in this standard are given in IEC 60851 .
The clause numbers used in this standard are identical with the respective test numbers of IEC 60851 .
In case of inconsistencies between the publication on methods of test and this standard,IEC 60317-1 1 shall prevail.
