BSI BS IEC 60870-5-6 pdf download Telecontrol equipment and systems — Part 5-6: Guidelines for conformance testing for the IEC 60870-5 companion standards
1 Scope
This part of the IEC 60870-5 series specifies methods for conformance testing of telecontrol equipment, amongst Substation Automation Systems (SAS) and telecontrol systems, including front- end functions of SCADA.
The use of this part of IEC 60870-5 facilitates interoperability by providing a standard method of testing protocol implementations, but it does not guarantee interoperability of devices. It is expected that using this part of IEC 60870-5 during testing will minimize the risk of non- interoperability.
The goal of this part of IEC 60870-5 is to enable unambiguous and standardised evaluation of IEC 60870-5 companion standard protocol implementations. The guidelines and conditions for the testing environment are described in this part of IEC 60870-5. The detailed test cases per companion standard, containing among others mandatory and optional mandatory test cases per Basic Application Function, ASDU and transmission procedure, will become available as technical specifications (IEC 60870-5-60x). Other functionalities may need test cases, but this is beyond the scope of this part of IEC 60870-5.
This part of IEC 60870-5 deals mainly with communication conformance testing; therefore other requirements, such as safety or EMC are not covered. These requirements are covered by other standards (if applicable) and the proof of compliance for these topics should be done according to those standards.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated of the referenced document (including any amendments) applies.
IEC 60870-5-1 , Telecontrol equipment and systems – Part 5: Transmission protocols – Section One: Transmission frame formats
IEC 60870-5-2, Telecontrol equipment and systems – Part 5: Transmission protocols – Section 2: Link transmission procedures
IEC 60870-5-3, Telecontrol equipment and systems – Part 5: Transmission protocols – Section 3: General structure of application data
IEC 60870-5-4, Telecontrol equipment and systems – Part 5: Transmission protocols – Section 4: Definition and coding of application information elements
IEC 60870-5-5, Telecontrol equipment and systems – Part 5: Transmission protocols – Section 5: Basic application functions
ISO/IEC 9646 (all parts), Information technology – Open Systems Interconnection – Conformance testing methodology and framework
3 Terms and definitions
For the purposes of this part of IEC 60870-5, the following terms and definitions apply.
3.1
configuration (of a system or device)
step in system design: selecting functional units, assigning their locations and defining their interconnections
3.2
configuration list
supplies an overview of all compatible hardware and software versions of components of controlled/controlling stations including the software versions of relevant supporting tools
3.3
address config
address config is the configuration file containing the ASDU-addressing including the information object addresses necessary to test all the functionality defined as in the PID
