BS ISO 12090-1 pdf download Rolling bearings — Profiled rail guides for linear motion rolling bearings Part 1: Boundary dimensions and tolerances for series 1, 2 and 3
1 Scope
This part of lSO 12090 establishes the boundary dimensions and tolerances for series 1, 2 and 3 of linearmotion rolling bearings, profiled rail guides.
These bearings consist of profiled rails with carriages，which can support forces from all perpendiculardirections and moments around all axes and consist of recirculating rolling elements. The internal design ofthese profiled rail guides is at the discretion of the manufacturer.
An assembly，as specified by the manufacturer，can comprise one or more carriages on a profiled rail.Therefore, the interchange or combination of these elements can only be carried out within the limits permittedby the manufacturer.
2Normative references
The following referenced documents are indispensable for the application of this document. For datedreferences,only the edition cited applies. Forundated references,the latest edition of the referenceddocument (including any amendments) applies.
ISO 1132-1，Rolling bearings — Tolerances — Part 1: Terms and definitionsISO 5593，Rolling bearings — Vocabulary
ISO 15241,Rolling bearings — Symbols for quantities
ISO 24393, Rolling bearings —Linear motion rolling bearings — Vocabulary
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 1132-1, ISO 5593,ISO 24393 andthe following apply.
3.1
linear rail guideprofiled rail guide
(monorail guidance system) linear motion rolling bearing unit consisting of a profiled rail or profiled guidewayand one or more ball carriages or roller carriages
NOTE Adapted from lSO 24393:2008, definition 02.02.01.
3.2
ball carriage profiled rail guide
linear rail guide consisting of one or more ball carriages and a profiled rail or profiled guideway
[ISO 24393:2008, definition 02.02.03]
NOTE The amount of linear movement (stroke length) is unlimited as the ball carriage has a ball recirculating feature.
3.3
roller carriage profiled rail guide
linear rail guide consisting of one or more roller carriages and a profiled rail or profiled guideway
[ISO 24393:2008, definition 02.02.04]
NOTE The amount of linear movement (stroke length) is unlimited as the roller carriage has a roller recirculating feature.
3.4
ball carriage
linear bearing subassembly consisting of a ball carriage body and a number of closed loops of recirculating balls, which is designed to achieve unlimited motion along a profiled rail or profiled guideway
[ISO 24393:2008, definition 03.01 .02]
3.5
roller carriage
linear bearing subassembly consisting of a roller carriage body and a number of closed loops of recirculating rollers, which is designed to achieve unlimited motion along a profiled rail or profiled guideway
[ISO 24393:2008, definition 03.01 .03]
3.6
profiled rail
profiled guideway
rail or guideway having a profiled cross-section incorporating a number of raceways along which a ball carriage or a roller carriage traverses
NOTE Adapted from ISO 24393:2008, definition 04.01 .1 5.
3.7
nominal carriage width
A
distance between the two faces of a carriage
3.8
reference face of a carriage
face of a carriage designated as the reference face by the manufacturer of the guide and which can be the datum for measurements
3.9
reference face of a profiled rail
face of a profiled rail designated as the reference face by the manufacturer of the guide and which can be the datum for measurements
3.10
nominal distance between the reference face of carriage and the reference face of the rail
A 1
distance between the two reference faces of the carriage and profiled rail (of profiled rail guide)
